ASTM B 111 C12000 Seamless Copper Pipe

ASTM B 111 C12000 Seamless Copper Pipe

Copper Pipe / Astm Sb 111 C11000 Seamless Copper Pipe

ASTM B111 C11000 Seamless Copper Pipe is a high-quality electrolytic tough pitch copper pipe known for excellent thermal and electrical conductivity, superior corrosion resistance, and good mechanical strength. Manufactured to ASTM B111 standards, it ensures reliable performance and dimensional accuracy. Common applications include heat exchangers, condensers, HVAC systems, plumbing, refrigeration, and industrial fluid transport where durability and efficiency are essential.

  • Description
  • Chemical Composition
  • Physical Properties
  • Sizes Available

High electrical and thermal conductivity, good corrosion resistance and solderability. C11000 is used for welding fixtures, anodes, bus bar in electrical power installations, ground straps, commutators and current carrying hardware. Its inherent fabrication qualities readily permit it to be bent, soldered, drilled, peened, riveted and formed to fit almost any design specification.


Equivalent Specifications

SPECIFICATIONSDESIGNATION
ISOCu-ETP
EuropenCu-ETP
BSCu-ETP-2
JISC-1100
RussianMO

Chemical Composition

 Cu0
Min/Max99.90 min-
Nominals-0.0400

Physical Properties

Coefficient of Thermal Expansion9.4 10−6Per °F (68-212 F)
9.6 10−6Per °F (68-392 F)
9.8 10−6Per °F (68-572 F)
Density0.322 lb/in3 @ 68 F
Electrical Conductivity101%IACS @ 68 F
Electrical Resistivity10.3 ohms-cmil/ft @ 68 F
Melting Point Liquid US1981 F
Melting Point Solid US1949 F
Modulas of Elasticity in Tension17000 ksi
Modulas of Rigidity6400 ksi
Specific Gravity8.91
Specific Heat Capacity0.092 Btu/lb/°F @ 68 F
Thermal Conductivity226.0 BTU in/hr.ft2.°F @ 68 F

Sizes Available

HOLLOW RODSMin Bore Size 20 mm and Max OD 100 mm
ROUND RODS/RODS8mm To 100 mm
HEX10mm To 60mm
SQUARE10mm To 60mm
FLAT10mm Min Thickness and max Width 120mm
BILLETSUp to 200 mm
INGOTSAS per Specification
